Stainless Wire

Short Description:

Stainless Steel Wire are used in a number of industries including wire-drawing, mesh weaving, soft pipe, isolation layer and clean ball in kitchen, steel rope, filter material, making of spring and nails, medicine and petrochemical.

Send email to us Download PDF

Product Detail

Tags

Details：

Usage: Stainless Steel Wire are used in a number of industries including wire-drawing, mesh weaving, soft pipe, isolation layer and clean ball in kitchen, steel rope, filter material, making of spring and nails, medicine and petrochemical.

Material: 301, 302, 304, 304L, 316, 316L, 430, 430A etc.

Features: Anti-rust, high strength, good tenacity and anti radiating properties.

Weaving method: N/A

Other: Payment: 30% first TT, or L/C at sight.

Tengyuan are experienced in producing all kinds of stainless steel wire of complete sizes. There are stainless steel wires for weaving up to heavy duty stainless steel wires. for cold heading, for stainless steel mesh or stainless steel tying wire. Tengyuan is range includes 201, 202, 301, 302, 304, 304L, 316, 316L, 430, 430A etc. Diameter from 5.00mm to 0.025mm. All our products are manufactured to the highest quality and supplied within the scope of our ISO 9001accreditation.

Stainless Steel Wire possess many good properties, such as anti-rust, bright color, good tenacity, high strength, good preventing and anti-radiating and so on.

As a kind of basic industrial material, Stainless Steel Wire are widely used in a number of industries including wire-drawing, mesh weaving, soft pipe, isolation layer and clean ball in kitchen, steel rope, filter material, making of spring and nails, medicine and petrochemical.

Wire Diameter(mm)	Tolerance(mm)	Max. Deviation Tolerance (mm)
0.020-0.049	+0.002/-0.001	0.001
0.050-0.074	0.002	0.002
0.075-0.089	0.002	0.002
0.090-0.109	+0.003/-0.002	0.002
0.110-0.169	0.003	0.003
0.170-0.184	0.004	0.004
0.185-0.199	0.004	0.004
0.200-0.299	0.005	0.005
0.300-0.310	0.006	0.006
0.320-0.499	0.006	0.006

Standard Stainless Steel Wire fall in grades as follows:

AISI Grade	Chemical Composition(%)
	C	Si	Mn	P	S	Ni	Cr	Mo
301	=0.15	=1.0	=2.0	=0.04	=0.03	=7	16.00~18.00	-
302	=0.15	=1.0	=2.0	=0.04	=0.03	=8	17.00~19.00	-
304	=0.08	=1.00	=2.00	=0.045	=0.030	8.00~10.50	18.00~20.00	-
304H	0.08	=1.00	=2.00	=0.045	=0.030	8.00~10.50	18.00~20.00	-
304L	=0.030	=1.00	=2.00	=0.045	=0.030	9.00~13.50	18.00~20.00	-
316	=0.045	=1.00	=2.00	=0.045	=0.030	10.00~14.00	10.00~18.00	2.00~3.00
316L	=0.030	=1.00	=2.00	=0.045	=0.030	12.00~15.00	16.00~18.00	2.00~3.00
430	=0.12	=0.75	=1.00	=0.040	=0.030	=0.60	16.00~18.00	-
430A	=0.06	=0.50	=0.50	=0.030	=0.50	=0.25	14.00~17.00	-
