Specification List of Window Screen Netting

Variety

Specification

Technical Notes

Mesh/Inch

Wire Gauge

Roll Size

Gal.Iron Wire Netting

10 x 10

BWG31 BWG32 BWG33 BWG34

Process: Electric galvanized after weaving Color: White or blue white

14 x 14

16 x 16

18 x 18

18 x 14

22 x 22

24 x 24

Enamelled Iron Wire Netting

Same as above

Green or dark green

Aluminum Coated Iron Wire Netting

Same as above

Silver

Aluminum Wire Netting

Same as above

Material: Al-mg alloy or pure aluminum Painted aluminum wire netting epoxy resin paint

Fiberglass Wire Netting

12 x 12

BWG31 BWG32

3'x100' 4'x100' 1x25M 1.2x25M

Available in different colors

14 x 14

16 x 16

16 x 14

PVC Wire Netting

12x 12

As above

Twisted weaving:12*14*16mesh; Plain weaving:18*22*24mesh; Colors available:white,blue,green,etc.

14 x 14

16 x 16

18 x 18

18 x 14

20 x 20

Stainless Steel Wire Netting

14 x 14 SWG38 16 x 16 SWG37 18 x 18 SWG36 18 x 14 SWG35 20 x 20 SWG34

3'x100' 4'x100' 1x25M 1.2x25M

Materials: Stainless steel 304*316*316L

PVC Coated Wire Netting

12x 12

BWG31 BWG32

As above

Different colors available. Used in petroluem, pipes wrapping.
